All Aluminum Anti-Static Floor
Characteristics
1. Floor component standard, high precision, easy construction and good interchangeability.
2. High load structure design, erection height can be adjusted.
3. High wear resistance of PVC covering, effectively solve the veneer fracture, warping and other problems.
4. Customer can choose panel color, material and function according to the requirements.
5. Moisture proof. Rust - proof, fire - proof, durable, recycle long- term used floor material.
6. Good ventilation performance: 15%-50%.
7. The floor can be used for class 10 to class 100,000 purification rooms.
Technical Specification
| Intermationa | Size (mm) | Fire Performance | Concentrated load | Impact load (N) |
UItimate load (N) |
Uniform load (N/m²) |
Rolling load(N) | |||
| (LB) | (N) | (Kg) | 10/Times | 10000/Times | ||||||
| FS800 | 600x600x40 | A | ≥800 | ≥3350 | ≥363 | ≥536 | ≥11250 | ≥16100 | 3560 | 2670 |
| FS1000 | 600x600x40 | A | ≥1000 | ≥4550 | ≥453 | ≥670 | ≥13350 | ≥23000 | 4450 | 3560 |
| FS1250 | 600x600x50 | A | ≥1250 | ≥5560 | ≥567 | ≥780 | ≥16680 | ≥33000 | 5560 | 4450 |
| FS1500 | 600x600x50 | A | ≥1500 | ≥6675 | ≥670 | ≥1005 | ≥19892 | ≥34500 | 6675 | 5340 |
| FS2000 | 600x600x50 | A | ≥2000 | ≥8900 | ≥906 | ≥1340 | ≥26700 | ≥4600 | 8900 | 8000 |
