All Steel Anti-Static Access Floor With Edge Trims

Short Description:

The steel access floor surface is sticked with PVC covering, make full use of the plastic particle interface between the formation of electrostatic network, so that it has a permanent anti-static function, and the appearance of the surface looks like marbling, with a better decorative effect.

Send email to us

Product Details

Product Video

Characteristics

1. Made of steel, large bearing capacity, strong impact resistance.

2. Filled with special foam cement, which makes it feel comfortable and stable, with good sound absorption, heat insulation and fire resistance.

3. Use imported glue, wear resistance, no foaming, no degumming, steel shell electrostatic spray, lighting, wear resistance, decorative strong.

4. The floor is decorated with black guide electrostatic bar, which further strengthens the anti-static function of the system and makes the appearance more beautiful.

5. All around support, easy to install, flexible assembly, lower space can be used for air conditioning ventilation, easy maintenance.

6. Height of pedestal: 80mm-300mm, other height can be customized.

Technical Specification

International	Size (mm)	Fire Performance	Concentrated load			Impact load (N)	Ultimate load （N)	Uniform load (N/m²)	Rolling load(N)
International	Size (mm)	Fire Performance	(LB)	(N)	(Kg)	Impact load (N)	Ultimate load （N)	Uniform load (N/m²)	10/Times	10000/Times
FS440	600x600x35	A	≥440	≥196	≥20c	≥295	≥5880	≥9272	1958	1566
FS662	600x600x35	A	≥662	≥2950	≥301	≥445	≥8850	≥12500	2946	2356
FS800	600x600x35	A	≥800	≥3350	≥363	≥536	≥11250	≥16100	3560	2670
FS1000	600x600x35	A	≥1000	≥4550	≥453	≥670	≥13350	≥23000	4450	3560
FS1250	600x600x35	A	≥1250	≥5560	≥567	≥780	≥16680	≥33000	5560	4450
FS1500	600x600x35	A	≥1500	≥6675	≥670	≥1005	≥19892	≥34500	6675	5340
FS2000	600x600x35	A	≥2000	≥8900	≥906	≥1340	≥26700	≥4600	8900	7120
